Specification Summary

  • Centrifugal ANSI B73.1 Process Pump Model Griswold 811M-4x3-8G, flow rate of 320 gpm  at 3000 rpm, total head 104 ft, maximum discharge pressure 45 psig
  • Baldor NEMA Motor Type 0940M, 20 hp (15kW)/ 3 phase/ 380VAC/ 4 pole/ 2925 rpm/ 50 hz, NEMA Design B, Insulation Class F, TEFC, SF1.15, 284TS Frame
  • Suction pipe size of 8 in NPS and discharge pipe size of 6 in NPS
  • The Pump Skid is equipped with MCC F2100 series Eaton Cutle Hammer 20hp, John Crane Seal Pot, Pressure Indicator

Code Compliance

  • API Std 610 – Centrifugal Pump for Petroleum, Petrochemical and Natural Gas Industries
  • ISO 5167-1:2003 – Measurement of fluid flow

We did

  • Engineering works, such-as Calculation of NPSH & Power required, Structural Skid Analysis, Shaft Coupling Selection, 3-D Modeling, Isometric Drawings, Construction Drawings, Electrical & Instrument Drawing
  • Fabrication, testing & inspection, coating of structural skid and on-skid piping
  • Installation of pump, motor and flexible coupling, including shaft alignment
  • Installation of Electrical & Instrument
  • Assembly & Install MCC F2100 series Eaton Cutler Hammer 20 HP
  • Performance test at shop

Safety summary

  • Total 1845 working hours
  • Lost time injury – 0
  • Day lost incident – 0
  • Near misses reported – 0
